Proven Methods For How To Get A Broken Tap Out Of A Hole

Removing a broken tap—a high-hardness steel cutting tool sheared off inside a workpiece—requires a combination of precision chemistry, thermal manipulation, or mechanical disintegration. Success hinges on neutralizing the mechanical bond without damaging the parent material threads, typically utilizing specialized tap extractors, EDM (Electrical Discharge Machining) units, or acidic erosion for ferrous alloys.

Pre-Operation Setup and Tooling Requirements

Before initiating the extraction, you must evaluate the tap material. High-speed steel (HSS) taps are brittle and prone to work-hardening if attacked with improper tools like hardened punches or drills, which will only lead to further tool breakage and material ruin. Assess the workpiece for material constraints; aluminum and mild steel require vastly different approaches than hardened tool steel or stainless steel alloys.

• Essential Gear and Materials


  • Penetrating oil or professional-grade cutting fluid with high sulfur content to reduce friction.
  • Carbide-tipped tap extractors (matching the flutes of the broken tap).
  • High-speed steel or carbide burrs and a high-speed rotary tool (Dremel).
  • Center punch and a high-quality hammer for alignment.
  • Optional: Alum (potassium aluminum sulfate) for chemical dissolution of steel in aluminum.
  • Optional: Magnetic pickup tool or compressed air for debris removal.
• Mandatory Prerequisites


  • Ensure the workpiece is securely clamped to a heavy-duty workbench or milling machine table to prevent movement, which would cause the remaining tap shard to snap further.
  • Verify the tap size (e.g., M6, 1/4-20) to ensure the extractor fingers match the geometry of the flutes.
• Benchmark Estimates


  • Extraction success rate for manual removal: 60-70 percent for shallow breaks.
  • Professional EDM removal success rate: 95-99 percent.
  • Duration: 20 minutes for minor surface breaks to 4 hours for deeply seized, high-tensile fasteners.

Procedural Workflow for Broken Tap Extraction

Step 1: Cleansing and Inspection

Clear all chips, coolant residue, and debris from the hole using a pick, compressed air, or a thin nylon brush. It is vital to determine if the tap is broken flush with the surface, below the surface, or protruding. If the tap is slightly proud of the surface, you may have enough material to grip with locking pliers. If it is flush or recessed, proceed to mechanical or thermal extraction.

Step 2: The Tap Extractor Method

Insert the fingers of a tap extractor into the flutes of the broken tool. These extractors are made of hardened steel and are designed to slide into the groove between the flutes. Once inserted, slide the outer collar down against the workpiece to stabilize the fingers. Use a T-handle or small wrench to apply slow, consistent counter-clockwise pressure.

Warning: Do not apply side-loading pressure. Because taps are extremely hard, they are also brittle. Applying uneven torque will snap the extractor fingers off inside the tap, compounding the issue by creating a solid plug of hardened steel.

Step 3: Mechanical Grinding and Relieving

If the tap is stuck firmly, use a carbide burr in a high-speed rotary tool to grind away the center of the tap. Start at the center to relieve the tension that holds the flutes against the internal threads. Once the core is ground out, the remaining flutes will lose their structural integrity and can be picked out with a sharp scribe or a dental pick.

Pro-Tip: Use a diamond-coated burr if the tap is made of cobalt or tungsten carbide, as standard carbide burrs will dull instantly on these materials.

Step 4: The Chemical Dissolution Strategy

If the tap is in a non-ferrous material like aluminum or brass, use an alum solution. Dissolve alum in boiling water until saturated, then submerge the workpiece. The solution will slowly eat away the steel tap while leaving the aluminum or brass largely unaffected. This is a slow process that can take several hours, but it is the least invasive method for delicate or expensive castings.

Technical Comparison of Extraction Methods

Common Failure Scenarios and Field Remedies

• Failure: The tap extractor snaps off inside the broken tap flutes.


  • Root Cause: Excessive torque or improper seating of the extractor fingers.
  • Actionable Fix: Use a small carbide end mill in a milling machine to drill out the extractor and the tap simultaneously. If a mill is unavailable, professional EDM services are the only reliable recourse.
• Failure: The tap is hardened, and drilling is impossible with standard HSS bits.


  • Root Cause: HSS drill bits have a lower hardness rating than HSS taps.
  • Actionable Fix: Never attempt to drill a tap with a standard bit. Switch to a solid carbide drill bit or use an EDM unit to burn the core of the tap away.
• Failure: Threads are damaged during the removal process.


  • Root Cause: Forceful extraction or "cramming" the tap pieces against the sidewalls.
  • Actionable Fix: Once the tap is removed, clean the threads with a thread chaser or tap of the same size. If the threads are irreparably damaged, drill and tap for a larger size or install a thread insert (e.g., Helicoil).

Frequently Asked Questions

Can I weld a nut to the broken tap to back it out?

If the tap is broken proud of the surface and large enough (typically 3/8 inch or 10mm and larger), you can place a nut over the protrusion and weld the center. The heat from the welding process helps break the seized bond through thermal expansion and contraction, while the nut provides the leverage needed to back the tap out.

What is an EDM machine and why is it used for taps?

An Electrical Discharge Machine uses high-frequency electrical sparks to erode conductive material. It is the gold standard for tap removal because it removes the tap by vaporizing the metal without applying mechanical force, thereby leaving the threads of the workpiece completely intact.

How do I prevent taps from breaking in the future?

Use the correct tapping oil for the material, ensure the tap is perfectly aligned with the hole, and clear chips frequently by backing the tap out every half-turn (the "chip-breaking" technique). Always ensure the hole diameter is sized according to the correct drill-chart specification for the desired thread percentage.

Is it safe to drill out a broken tap?

It is generally unsafe to drill out a tap with handheld power tools. Because taps are hardened, they will cause a standard drill bit to "walk" or wander, leading to ruined threads. If you must use a drill, you must use a solid carbide drill bit and maintain perfectly rigid, vertical alignment, ideally using a drill press or mill.
